Schneider protection relay Easergy P1F 90-250V 3CT (REL15017)
Rp11.857.131
Deskripsi
Spesifikasi
| Range of product | Easergy P1 |
|---|---|
| Product or component type | Protection relay |
| Relay application | Feeder |
| product reference | P1 |
| device mounting | Flush |
| Mounting support | Fixing kit |
| Mounting mode | Flush-mounted |
| power supply | 90…240 V AC 90…250 V DC |
| measuring inputs | : 1/5 A CT phase current 8 |
| number of Digital Inputs (DI) | 8 |
| number of Digital Outputs (DO) | 6 DO 1 watchdog |
| type of temperature module connection | 1 twisted shielded pair |
| communication ports | RS485 1 rear USB type mini B 1 front |
| communication protocols | CEI 60870-5-103 Modbus RTU |
| Cybersecurity | Password protection |
| protection functions | Breaker failure 50BF Phase overcurrent 50/51 Earth fault overcurrent 50N/51N Lockout relay 86 Thermal overload protection 49 Cold load pick-up Switch ON to fault (SOTF) Inrush detection Negative sequence overcurrent 46 Broken conductor 46BC Recloser 79 |
| Arc flash protection | No |
| measurement functions | Current 3-phase Current RMS Current peak Current inrush Current positive sequence Current negative sequence Frequency Temperature overload |
| control functions | Local/remote control I/O push-button Digital Using serial port |
| monitoring functions | Circuit breaker monitoring Trip circuit supervision 74 Event counters Relay self-monitoring |
| logs and records | Event recording Disturbance recording Trip context information |
| Switchgear diagnosis type | Trip circuit supervision ANSI code: TCS |
| Connections – terminals | Snap-on fixed Screw clamp terminals fixed |
| Maximum power consumption in W | 13.5 W AC 4 W DC |
|---|---|
| Software name | ESetup Easergy Pro: device setup |
| Display type | And graphic display terminal |
| Number of key | 9 |
| Local signalling | 6 x LED red/orange programmable 1 x LED red relay trip indicator 1 x LED green watchdog |
| Device connection | Serial port 1 shielded twisted pair |
| Communication compatibility | IEC 60870-5-103 Modbus RTU |
| Standards | EN 60255-26:2009 EN 60255-1:2010 EN 60255-27:2005 |
| Product certifications | CE |
| Height | 101.5 mm embedded: 116.5 mm total: |
| Width | 101.5 mm embedded: 116.5 mm total: |
| Depth | 108 mm embedded: 119 mm total: |
| Net weight | 0.8 kg maximum |
