Advantech 5-port Ind. Unmanaged GbE Switch (EKI-2725-CE)
Deskripsi
SPESIFICATION
| Category | Attribute | Value |
| Power | Power Connector Type | 6-pin removable screw terminal |
| Power | Power Consumption | Max 2.5W |
| Power | Power Input (AC) | – |
| Power | Power Input (Battery) | – |
| Power | Power Input (DC) | 12 ~ 48 VDC |
| Power | Power Input (PoE) | – |
| Power | Redundant Dual Inputs | Yes |
| Protection | Overload Current | Present |
| Protection | Reverse Polarity | Present |
| Environment | Temperature (Max. Operating) | 60°C (140°F) |
| Environment | Temperature (Min. Operating) | -10°C (14°F) |
| Environment | Temperature (Operating Range) | -10 ~ 60°C (14 ~ 140°F) |
| Environment | Temperature (Storage Range) | -40 ~ 85°C (-40 ~ 185°F) |
| Mechanism | Dimensions (W x H x D) | 30 x 140 x 95 mm (1.18′ x 5.51′ x 3.74 in.) |
| Mechanism | Enclosure (Plastic) | – |
| Mechanism | IP Rating | IP30 |
| Mechanism | Mounting (DIN-rail) | Yes |
| Mechanism | Mounting (Panel) | – |
| Mechanism | Mounting (Pole Mount) | – |
| Mechanism | Mounting (Rack Mount) | – |
| Mechanism | Mounting (Stack) | – |
| Mechanism | Mounting (Wall) | Yes |
| Ethernet Communication | Fiber Port Connector Type | – |
| Ethernet Communication | Fiber Port Interface | – |
| Ethernet Communication | Fiber Port Number | – |
| Ethernet Communication | Fiber Transmission Distance | – |
| Ethernet Communication | Fiber Transmission Speed | – |
| Ethernet Communication | RJ-45 Port Connector Type | RJ-45 |
| Ethernet Communication | RJ-45 Port Number | 5 |
| Ethernet Communication | RJ-45 Transmission Distance | 100 m |
| Ethernet Communication | RJ-45 Transmission Speed | 10/100/1000 Mbps |
| Certification | EMI | CE, FCC Class A |
| Certification | EMS | EN 61000-4-2 (Level 3), EN 61000-4-3 (Level 3), EN 61000-4-4 (Level 3), EN 61000-4-5 (Level 3), EN 61000-4-6 (Level 3), EN 61000-4-8 (Level 3) |
| Certification | Safety | UL 60950-1 |
| Warranty | Warranty Period | 5 years |
| PoE Information | PoE Budget | – |
| PoE Information | PoE Output | – |
| PoE Information | PoE Port Number | – |
| PoE Information | Support PoE | No |
Informasi Tambahan
| Brand |
Advantech |
|---|
